Economical General use frequency inverter

VFD300

High performance and high precision three / single phase variable frequency drive VFD.

Adopts international advanced vector control algorithm.

Use the latest generation TI DSP, its computing speed increases 50%.

Support various PG card and electrical motors.

High Performance VC Frequency inverter

VFD500

AC induction motor, PMSM

Module design support IO expansion card and optional module card

Standard LED keypad, optional LCD keypad and support keypad copy function

Standard ModBus RS485; 3 optional field bus communication cards: Profibus-DP, CANopen, DeviceNet

Outstanding Features

Applicable motors: AC induction motor, PMSM

Standard LED keypad, optional LCD keypad and support keypad copy function

Module design support IO expansion card and optional module card

High torque control precision: ±8% rated torque(SVC), ±5% rated torque(FVC)

Wide speed regulation: VVF/1:50, SVC/1:200, FVC/1:1000 and High speed control precision: ±0.2% rated speed

Protections: Over-voltage stall, under-voltage, current limit, overload, overheat, over speed, over-voltage, etc.

Torque at low frequency: 1Hz/150%(VVF), 0.25Hz/150%(SVC), and 0Hz/180%(FVC)

Standard ModBus RS485; 3 optional field bus communication cards: Profibus-DP, CANopen, DeviceNet

Open loop vector control high performance frequency inverter

VFD700

Synchronous and asynchronous 3-phase induction motors are supported.

Work well with both surface mount pumps and submersible pumps.

Specially Designed with advanced MPPT and CVT technology.

Support remote monitoring online through GPRS remote monitor system.

If you are seeking for photovoltaic inverter for solar powered water pumping system, then you are already arrived to the right store. Our VFD700 inverter is definitely the appropriate choice for you.

Veikong VFD700 released to the global market at the end of 2015, is the updated version of VFD700 pumping inverter. Comparing with VFD700, the VFD700 series are of enhanced working performance such as in stability, efficiency and other functions. Since the announcement, VFD700 has gained more than 1000 successful application examples in various fields like agricultural irrigation, desertification control, stock farming, solar energy powered fountains and so forth. Below are the main features of VFD700:

1. Convert DC to AC power

VFD700 can convert the direct current generated by solar panels into alternating current to drive photovoltaic pumps.

2. Adjustable output frequency

It is capable of adjusting the output frequency automatically in line with the irradiation intensity.

3. Maximum Power Point Tracking function

Built-in with the MPPT (maximum power point tracking) function, so the photovoltaic pumping system can produce better power outputs to improve the working efficiency of pumps.

4. Store water, instead of storing power

The energy storing devices such as battery have been eliminated from the system, so all the AC power can be directly used to drive pumps with the lowest energy loss.

5. Asynchronous and synchronous motors are available

While our previous modal can only work with asynchronous 3 phase induction motors, the VFD700 series can work perfectly with both asynchronous and synchronous 3 phase induction motors.

6. Support various kinds of pumps

Both the surface mount and submersible pumps are compatible with the photovoltaic pumping system.

7. Remote monitor function

VFD700 has inbuilt S200-GPRS that users can monitor the whole photovoltaic pumping system online at home or other place via our PC remote monitoring system. On the basis of user-defined curve, VFD700 can automatically calculate the present flow speed, flow per day, present power, total generation and more status parameters of the solar pumping system.

8. Pc tool commissioning

As VFD700-PV has developed with the PC tool commissioning , so users can upload and download technical data and duplicate the data excel to monitor the PV pumping system offline at any time.

9. Complete protections

VFD700 has designed with a wide range of protection functions such as water fulfill, dry run, low frequency, high voltage, short circuit, over heat, phase missing and more.

10. User-friendly

VFD700 is designed with an intuitive operation panel along with detailed instructions, so it is convenient in installation, operation and maintenance. Additionally, the cooling and shielding effect is great.

Besides, Veikong Electric also provides other solar energy products such as PV inverter at wholesale price.

Solar frequency inverter

VFD500-PV

Synchronous and asynchronous 3-phase induction motors are supported.

Work well with both surface mount pumps and submersible pumps.

Specially Designed with advanced MPPT and CVT technology.

Support remote monitoring online through GPRS remote monitor system.

If you are seeking for photovoltaic inverter for solar powered water pumping system, then you are already arrived to the right store. Our VFD700-PV solar pump inverter is definitely the appropriate choice for you.

Veikong VFD700-PV high frequency solar inverter released to the global market at the end of 2015, is the updated version of VFD700 pumping inverter. Comparing with VFD700-PV, the VFD700-PV series are of enhanced working performance such as in stability, efficiency and other functions. Since the announcement, VFD700-PV has gained more than 1000 successful application examples in various fields like agricultural irrigation, desertification control, stock farming, solar energy powered fountains and so forth. Below are the main features of VFD700-PV:

1. Convert DC to AC power

VFD700-PV can convert the direct current generated by solar panels into alternating current to drive photovoltaic pumps.

2. Adjustable output frequency

It is capable of adjusting the output frequency automatically in line with the irradiation intensity.

3. Maximum Power Point Tracking function

Built-in with the MPPT (maximum power point tracking) function, so the photovoltaic pumping system can produce better power outputs to improve the working efficiency of pumps.

4. Store water, instead of storing power

The energy storing devices such as battery have been eliminated from the system, so all the AC power can be directly used to drive pumps with the lowest energy loss.

5. Asynchronous and synchronous motors are available

While our previous modal can only work with asynchronous 3 phase induction motors, the VFD700-PV series can work perfectly with both asynchronous and synchronous 3 phase induction motors.

6. Support various kinds of pumps

Both the surface mount and submersible pumps are compatible with the photovoltaic pumping system.

7. Remote monitor function

VFD700-PV AC frequency inverter has inbuilt S200-GPRS that users can monitor the whole photovoltaic pumping system online at home or other place via our PC remote monitoring system. On the basis of user-defined curve, VFD700-PV can automatically calculate the present flow speed, flow per day, present power, total generation and more status parameters of the solar pumping system.

8. Pc tool commissioning

As VFD700-PV has developed with the PC tool commissioning , so users can upload and download technical data and duplicate the data excel to monitor the PV pumping system offline at any time.

9. Complete protections

VFD700-PV has designed with a wide range of protection functions such as water fulfill, dry run, low frequency, high voltage, short circuit, over heat, phase missing and more.

10. User-friendly

VFD700-PV is designed with an intuitive operation panel, efficient solar pump controller and ac motor speed control, along with detailed instructions, so it is convenient in installation, operation and maintenance. Additionally, the cooling and shielding effect is great.

Soft Starter

S6000

The soft start motor has Intelligent digital motor soft start equipment system with the complete protection function.

The soft starter reduces the cost of system cost and extend the service life of the system..

It is a new ideal alternative for traditional star triangle starter and self-coupling decompression starter.

It improve the reliability of system and compatible with all the functions of starting equipment.

General purpose soft start motor control applications where traditional across-the-line starting or wye-delta starting would typically be appropriate. Typical application types include:

  • Motor Fan: Use soft starter instead of conventional starter, to realize the smooth start.
  • Compressor: The soft starter limit the startup current, reduce the abrasion and mechanical impact, reduce the heat of motor, prolong the working life, save the maintenance cost.
  • Crusher: The block protection of soft starter prevent the motor being over burnt and hurt damaged come from mechanical fault and block.
  • Transmission Machine: Soft startup and presetting slow movement realize smooth, gradual start, to avoid products movement and liquid overflow.
  • Pump: The control of soft starter reduce the water hammer result from liquid impact, saving maintenance cost for system.
  • Grinder: The soft start reduce the abrasion of wheels, lighten the maintenance cost and tiem.

Agitator

Air Compressor

Ball Mill

Centrifuge

Chiller

Conveyor

Crusher

Escalator

Fan (Low and High Inertia)

Feeder

Grinder

Hammer Mill

Lathe Machine

Mills (Flour, etc.)

Mixer (Unloaded or Loaded)

Pelletizer

Plastic and Textile Machines

Press (Flywheel)

Pump (Centrifugal)

Pump (Positive Displacement)

Rolling Mill

Saw (Band)

Saw (Circular)

Screen (Vibrating)

Transformer

Tumbler

Wood Chipper

Accessory

  • HDOM-IO-LOGIC

    HDOM-IO-LOGIC

  • Profibus Module

    Profibus Module

  • Remote Keypad

    Remote Keypad

  • Keypad Pallet

    Keypad Pallet

  • LCD Keypad

    LCD Keypad

  • HDOM-USB

    HDOM-USB

  • CANOPEN CARD

    CANOPEN CARD

  • INJECTION MOULDING

    MACHINE SIGNAL

    CONVETING CARD

    INJECTION MOULDING MACHINE SIGNAL

  • PG card

    PG card

  • ROTARY PG CARD

    ROTARY PG CARD

  • OPEN COLLECTOR

    PG CARD

    OPEN COLLECTOR PG CARD

  • DIFFERENTIAL

    PG CARD

    DIFFERENTIAL PG CARD

VFD200 smart mini variable speed drives

VFD200

VFD200 series inverter is a high-quality and simple VF control inverter.It can run a wide range of speed and torque control in high precision by decoupling control of motor magnetic flex current and torque current torque:fast and accurately,High end hardware platforms,scientific production technology and complete testing equipment make the product more stable and reliable.



  • 1,Using DSP as the core of control unit to achieve high-speed and high-performance control
  • 2,Motor parameter self-learning,intelligent setting to the optimal control model
  • 3,High performance IPM module,protection function such as under voltage,overcurrent,overtemperaature,over the ground short circuit etc.
  • 4,The unique EMC design minimizing the pollution to power



  • Applications
  • Generation power
  • Sawmills

  • water handing
  • Process industry
  • Material handing
